I D S
D020AA00
D020AA01
EN 341 type 2 class A (1) CE EN 12841 type C (2)
CE EN 15151-1 (3) ANSI Z359.4 (4)
NFPA 2500 Technical Use (5) EAC, UKCA
XF 494 Light Use GB/T 38230 II A (11)
600 g
I D L
D020BA00
D020BA01
EN 341 type 2 class A (6) CE EN 12841 type C (7)
ANSI Z359.4 (8) NFPA 2500 General Use (9)
EAC, UKCA
600 g
I D EVAC
D020CA00
D020CA01
EN 341 type 2 class A (1) CE EN 12841 type C (2)
ANSI Z359.4 (4) NFPA 2500 Technical Use (5)
EAC, UKCA
615 g
RIG
D021AA00
D021AA01
CE EN 12841 type C (2) EN 341 type 2 class A (1)
CE EN 15151-1 (10) NFPA 2500 Technical Use (5)
EAC, UKCA XF 494 Light Use
GB/T 38230 II A (11)
400 g
D020DA00 - - - 20 g
D020EA00 - - - 20 g
MAESTRO S D024AA00
CE EN 12841 type C, EN 341 NFPA 2500 Technical Use
EAC, UKCA XF 494 Light Use
GB/T 38230 II A (11)
1100 g
MAESTRO L D024BA00
CE EN 12841 type C, EN 341 NFPA 2500 General Use
EAC, UKCA XF 494 General Use GB/T 38230 II A (12)
1100 g
ZIGZAG D022AA00 CE UKCA 365 g
ZIGZAG PLUS D022BA00 CE UKCA 425 g
CHICANE D022CA00 255 g
HUIT D02 - 100 g
RACK D11 - 470 g
EXO AP HOOK D031DA00 NFPA 2500 Escape Use 1470 g
(1) EN 341 type 2 class A when used with a PARALLEL 10.5 mm or AXIS 11 mm rope (2) EN 12841 type C when used with a 10 to 11.5 mm EN 1891 A rope (3) EN 15151-1 when used with a 10 to 11 mm rope (4) ANSI Z359.4 when used with a 10 to 11.5 mm rope (5) NFPA 2500 Technical Use when used with a 10 to 11.5 mm rope (6) EN 341 type 2 class A when used with a VECTOR 12.5 mm rope
(7) EN 12841 type C when used with a 12.5 to 13 mm EN 1891 A rope (8) ANSI Z359.4 when used with a 12.5 to 13 mm rope (9) NFPA 2500 General Use when used with a 12.5 to 13 mm rope (10) EN 15151-1 when used with a 9 to 11 mm rope (11) With PARALLEL 10.5 mm, AXIS 11 mm, DURALINE 10.5 mm (12) With VECTOR 12.5 mm
Standard Descenders
HUIT Figure-eight descender Figure-eight descender, compact and lightweight. Square shape helps reduce rope twist.
RACK Variable friction descender with brake bars The design and configuration of the RACK bars make it easy to set up and insert the rope. Compact and lightweight, the device allows the user to adjust the amount of friction during the descent to adapt to changing conditions.
Personal Escape System
Lowering
Anti-panic function
Lowering
Certifications Rope Diameter Compatibility Working Load Limit Weight
Self-Braking Descenders
(yellow) (black)
10 to 11.5 mm Lowering a heavy load up to 250 kg
(yellow) (black)
12.5 to 13 mm Lowering a heavy load up to 280 kg
(yellow) (black)
10 to 11.5 mm Lowering a heavy load up to 250 kg
(yellow) (black)
10 to 11.5 mm Lowering a heavy load up to 200 kg
Open Auxiliary Brake for I D
Closed Auxiliary Brake for I D
Rescue Descenders
10.5 to 11.5 mm Lowering a heavy load up to 250 kg
12.5 to 13 mm Lowering a heavy load up to 280 kg
Mechanical Prusiks for Tree Care
11.5 to 13 mm 140 kg
11.5 to 13 mm 140 kg
CE, UKCA (with ZIGZAG or ZIGZAG PLUS
mechanical Prusik) 11.5 to 13 mm 140 kg
Standard Descenders
8 to 13 mm (single and double rope) 100 kg
9 to 13 mm (single rope) 8 to 11 mm
(double rope) 100 kg
Personal Escape System
7.5 mm (EXO rope only) 140 kg
Petzl Custom allows you to choose: - Rope type: Standard or high-strength rope - Rope color - Rope length - Type of rope-end connectors and harness connector The assembly of various components of your choice offers a ready-made solution specific to the user, delivered in a transport pouch or bag adapted to the length of the rope.
The anchor hook may be used around a structure, secured with a locking hitch.
If the user pulls too hard on the handle, the anti-panic function brakes and stops the descent automatically.
Because of the unique shape of the anchor hook, special Petzl training for the EXO AP HOOK is mandatory.
EXO® AP HOOK Personal escape system with anchor hook EXO AP HOOK is a personal escape system with a HOOK anchor hook, adapted for situations where the possibility of finding an anchor point is uncertain. It has a self-braking system with anti-panic function for quickly moving horizontally, climbing through a window, and controlling or stopping a descent. If the user pulls too hard on the handle, the anti-panic function brakes and stops the descent automatically. EXO AP HOOK also includes a rope that resists wear and high temperatures, an Am D connector with CAPTIV positioning bar, and a bag for transporting and attaching the system directly to the harness. Other rope lengths and other types of connectors (such as the EASHOOK OPEN) are available by special order.
Descenders
