DUO Z1 E80BHR E80BHR UK
ATEX zone 1/21 II 2 GD Ex ib IIB T4 Gb
IIIB T135° C Db Ambient temperature:
-20° C to +40° C
- - 6400 mAh
PIXA Z1 E78DHB 2
ATEX zone 1/21 II 2 GD Ex ib IIB T4 Gb
IIIB T135° C Db Ambient temperature:
-20° C to +40° C
- -
PIXA 3R E78CHR 2 E78CHR 2UK
ATEX zone 2/22 II 3 GD Ex ic IIB T4 Gc
IIIC T135° C Dc Ambient temperature:
-30° C to +40° C
- - 930 mAh
PIXA 3
E78CHB 2
ATEX zone 2/22 II 3 G Ex nA ic IIB T4 Gc,
II 3 D Ex tc IIIC T135° C Dc Ambient temperature:
-30° C to +40° C
- -
E78CHB 2UL -
HAZLOC Class I Div 2 Groups C, D
Class II Div 2 Group G Temperature code T4 Ambient temperature:
-30° C to +40° C
-
PIXA 2
E78BHB 2
ATEX zone 2/22 II 3 G Ex nA ic IIB T4 Gc,
II 3 D Ex tc IIIC T135° C Dc Ambient temperature:
-30° C to +40° C
- -
E78BHB 2UL -
HAZLOC Class I Div 2 Groups C, D
Class II Div 2 Group G Temperature code T4 Ambient temperature:
-30° C to +40° C
-
PIXA 1
E78AHB 2
ATEX zone 2/22 II 3 G Ex nA ic IIB T4 Gc,
II 3 D Ex tc IIIC T135° C Dc Ambient temperature:
-30° C to +40° C
- -
E78AHB 2UL -
HAZLOC Class I Div 2 Groups C, D
Class II Div 2 Group G Temperature code T4 Ambient temperature:
-30° C to +40° C
-
Choosing your Petzl headlamp for hazardous areas in accordance with regulations: Brightness is the total quantity of light emitted by a lamp. It is expressed in lumens. The greater the quantity of light, the better you see. The value indicated is that of the most powerful lighting level (MAX POWER).
Petzl headlamps that work with rechargeable batteries.
Lighting distance is linked to brightness and beam shape. It is expressed in meters and indicates the range of usable lighting. The value indicated is the maximum value.
Petzl headlamps that work with regular batteries (included).
Burn time expresses the length of time a headlamp functions with power sufficient for carrying out an activity. It is expressed in hours. The value indicated is the maximum value.
Headlamp meeting ATEX certification requirements for work in hazardous environments.
When the battery is almost drained, the headlamp switches automatically to reserve lighting to provide minimum lighting for several hours.
Headlamp meeting HAZLOC certification requirements for work in hazardous environments.
Wide beam designed for proximity lighting, to see up close or around the feet. The wide angle provides a very large and comfortable field of view.
Better resistance to chemicals.
Mixed beam consists of a wide beam and a focused component, allowing both proximity lighting and longer- range vision for moving around.
The IP rating on a headlamp indicates its degree of resistance to intrusions: IPX4: Water-spray and weather resistant IPX7: Resistant to temporary immersion (in up to 1 meter for 30 minutes) IP67: Resistant to dust and temporary immersion (in up to 1 meter for 30 minutes)
Focused beam allows focused lighting on a target in order to see objects or people at a distance.
The IK rating on a headlamp indicates its degree of protection against impacts. IK05: Protected against a 0.70-joule impact, equivalent to the impact of a 0.2 kg mass dropped from 350 mm above the impacted surface. IK06: Protected against a 1-joule impact, equivalent to the impact of a 0.5 kg mass dropped from 200 mm above the impacted surface. IK07: Protected against a 2-joule impact, equivalent to the impact of a 0.5 kg mass dropped from 400 mm above the impacted surface.
Red lighting for more comfortable night vision. This lighting allows good vision without blinding the user or members of a group.
The weight indicated is that of the headlamp with its energy source (regular or rechargeable batteries).
Red, green, and blue lighting allows the user to better see contrasts in the lit object in certain situations. Resistance to falls (2 m).
Red and/or white strobe lighting allows you to signal and be more easily located, for example in an emergency. Resistance to crushing (80 kg).
Headlamp SpecificationsEnvironments and Standards
