PRO TRAXION P055AA00

CE EN 567, EN 12278 EN 12841 type B

NFPA 2500 Technical Use Pulley and Rope grab

UKCA XF 494 Pulley Light Use (6)

XF 494 Rope Grab Light Use (6)

38 mm 95 % 295 g

MINI TRAXION P054AA00 32 mm 93 % 150 g

MINI P59A CE EN 12278 NFPA 2500

Technical Use UKCA

25 mm 91 % 2,5 kN x 2 = 5 kN 80 g

GEMINI P66A CE EN 12278 NFPA 2500

Technical Use UKCA

25 mm 91 % 2 x 1,5 kN x 2 = 6 kN 135 g

MINDER P60A CE EN 12278

NFPA 2500 General Use UKCA

XF 494 General Use 51 mm 97 % 4 kN x 2 = 8 kN 295 g

TWIN P65A CE EN 12278

NFPA 2500 General Use UKCA

XF 494 General Use 51 mm 97 % 2 x 3 kN x 2 = 12 kN 450 g

MOBILE P03A CE EN 12278 UKCA 21 mm - 71 % 2,5 kN x 2 = 5 kN 75 g

FIXE P05W P05WN (1) CE EN 12278

UKCA XF 494 Light Use

21 mm - 71 % 2,5 kN x 2 = 5 kN 90 g

REEVE P005AA00 CE EN 12278

NFPA 2500 General Use UKCA

XF 494 General Use 38 mm 95 % 4 kN x 2 = 8 kN 650 g

TANDEM P21 CE EN 12278 UKCA 21 mm - 71 % 10 kN 195 g

TANDEM SPEED P21 SPE

CE EN 12278 UKCA 27,5 mm 95 % 10 kN 270 g

KOOTENAY P67 CE EN 12278

UKCA XF 494 Light Use

76 mm - 5 kN x 2 = 10 kN 1390 g

ROLLCAB P47 CE EN 1909 UKCA 55 mm - - 5 kN 1470 g

JAG SYSTEM

1 m 2 m 5 m

P044AA00 P044AA01 P044AA02

EN 358 EAC

UKCA - 91 % 6 kN

610 g 805 g 1460 g

JAG TRAXION P54

CE EN 567 NFPA 2500 Technical Use

UKCA 25 mm 91 % 2 x 1,5 kN x 2 = 6 kN 145 g

JAG P45 CE EN 12278

NFPA 2500 Technical Use UKCA

25 mm 91 % 2 x 1,5 kN x 2 = 6 kN 120 g

TWIN RELEASE P001DA00

CE EN 567 EN 12278 (4) NFPA 2500

Pulley General Use NFPA 2500 Rope Grab

Techical Use (5) UKCA

XF 494 Pulley General Use XF 494 Rope Grab Light Use

40 mm 38 mm 95 % 280 kg 800 g

SPIN L1 P001BA00 P001BA01 (1) CE EN 12278 NFPA 2500

Pulley General Use UIAA UKCA

XF 494 Light Use

38 mm 95 %

4 x 2 = 8 kN 290 g

SPIN L2 P001CA00 P001CA01 (1) 8 kN (3) 480 g

SPIN L1D P001AA00 CE (2)

NFPA 2500 Pulley General Use

UKCA 40 mm 93 % 3 x 2 = 6 kN 425 g

SPIN S1 P002AA00 P002AA01 (1) CE EN 12278 NFPA 2500

Pulley Technical Use UIAA UKCA

25 mm 91 % 2,5 x 2 = 5 kN

145 g

SPIN S1 OPEN P002BA00 160 g

PARTNER P52A CE EN 12278 UKCA 25 mm 91 % 2,5 kN x 2 = 5 kN 56 g

RESCUE P50A P50AN (1)

CE EN 12278 NFPA 2500 General Use

UKCA XF 494 General Use

38 mm 95 % 4 kN x 2 = 8 kN 185 g

ROLLCLIP A

P74 TL CE EN 362 EN 12275 EN 12278

EAC, UKCA 18 mm 85 % 2 kN x 2 = 4 kN 115 g

P74 CE EN 12275

EN 12278 EAC, UKCA

105 g

ROLLCLIP Z P75 TL CE EN 362

EN 12278 EAC

UKCA 18 mm 85 % 2 kN x 2 = 4 kN

110 g

P75 SL 105 g

Haul System

The cam can be locked in the open position to make it easier to feed slack.

Release of the cam and passage of the rope through the brake integrated into the main moving side plate, allows comfortable and precise control when lowering.

TWIN RELEASE Releasable double progress-capture pulley for haul systems Releasable, the TWIN RELEASE progress-capture pulley is designed to set up 4:1 haul systems for work in confined spaces or for technical rescue. It s possible to release the cam using the ergonomic handle. When lowering heavy loads, the brake integrated into the moving side plate and the main faceted sheave with single-direction rotation offer additional braking and better control. The two sheaves provide excellent hauling efficiency. The swivel makes it easier to operate, allowing the pulley to be oriented under load and for carabiners, ropes, or slings to be directly connected.

(1) Black pulleys, (2) CE based on the relevant requirements of the EN 12278 standard, (3) 3 kN per arm, more information in Instructions for Use, (4) partial CE EN 12278: meets performance requirements of the CE EN 12278 standard, (5) system certification: ANSI Z359.4 Synthetic Rope Tackle Block (more information in the Instructions for Use), (6) only for the PRO TRAXION.

Pulleys

Certifications Rope Diameter Compatibility Sheave

Diameter Ball Bearings Efficiency Working Load Limit Weight

High-Efficiency Pulleys With Swivel

7 to 13 mm

8 to 13 mm

7 to 11 mm

High-Efficiency Pulleys

7 to 11 mm

7 to 13 mm

Pulley-Carabiners

7 to 13 mm

7 to 13 mm

Certifications Rope Diameter Compatibility Sheave

Diameter Ball Bearings Efficiency Working Load Limit Weight

Progress-Capture Pulleys

8 to 13 mm Pulley:

11.5 kN x 2 = 23 kN Rope clamp: 4 kN

7 to 11 mm Pulley:

10 kN x 2 = 20 kN Rope clamp: 4 kN

Prusik Pulleys

7 to 11 mm

7 to 11 mm

7 to 13 mm

7 to 13 mm

Single Pulleys

7 to 13 mm

7 to 13 mm

Transport Pulleys

7 to 13 mm

Rope 13 mm

Rope 13 mm

8 to 19 mm

Cable 55 mm

Haul System

8 mm

8 to 11 mm

8 to 11 mm

8 to 13 mm

TWIN RELEASE progress-capture pulley
