ASAP’AXIS
11 mm
R074DA00 10 m
CE EN 1891 type A 82 g
R074DA01 20 m
R074DA02 30 m
R074DA03 40 m
R074DA04 50 m
R074DA05 60 m
AXIS
11 mm
R074BA00 10 m
CE EN 1891 type A
NFPA 2500 Technical Use
EAC
XF 494 Light Use
82 g
R074BA01 20 m
R074BA02 30 m
R074BA03 40 m
R074BA04 50 m
R074BA05 60 m
RAY
11 mm
R100BA00 25 ft
ANSI Z359.15
ANSI Z459.1
NFPA 2500
98 g
R100BA01 50 ft
R100BA02 75 ft
R100BA03 100 ft
R100BA04 200 ft
ASAP’SORBER
L071AA00 20 cm
CE EN 355
ANSI Z359.13 6 feet
EAC
GB/T 24538 Type II
125 g
L071AA01 40 cm 145 g
ASAP’SORBER
AXESS
L071CB00 40 cm
CE EN 355
ANSI Z359.13 6 feet
GB/T 24538 Type II
205 g
ASAP
B070AA00 295 g
ASAP LOCK
B071BA00 425 g
with sewn
termination
with sewn
termination
Lengths Certifications
Weight
per Meter
Ropes for Mobile Fall Arresters
Lengths Certifications Weight
Absorbers for Mobile Fall Arresters
Certifications Weight
Mobile Fall Arresters
CE EN 12841 type A
when used with an OK TRIACT-LOCK carabiner and an EN 1891 type A 10-13 mm rope.
An ASAP’SORBER or ASAP’SORBER AXESS energy absorber can be used when needed.
CE EN 353-2
when used with an OK TRIACT-LOCK carabiner and an ASAP’AXIS 11 mm rope.
An ASAP’SORBER or ASAP’SORBER AXESS energy absorber can be used when needed.
ANSI Z359.15
when used with an ASAP’SORBER or ASAP’SORBER AXESS energy absorber,
a Bm’D or OXAN TRIACT-LOCK (international version) carabiner,
a CAPTIV positioning bar, and a RAY 11 mm static rope with sewn termination.
EAC
when used with an OK TRIACT-LOCK carabiner and an EN 1891 type A 10-13 mm rope.
An ASAP’SORBER or ASAP’SORBER AXESS energy absorber can be used when needed.
XF 494 Light Use
GB/T 24537 when used with an OK TRIACT-LOCK carabiner and an ASAP’SORBER
or ASAP’SORBER AXESS energy absorber.
CE EN 12841 type A
when used with an ASAP’SORBER or ASAP’SORBER AXESS energy absorber,
and an EN 1891 type A 10 to 13 mm rope.
CE EN 353-2
when used with an ASAP’SORBER or ASAP’SORBER AXESS energy absorber
and an AXIS 11 mm rope with sewn termination.
ANSI Z359.15
when used with an ASAP’SORBER or ASAP’SORBER AXESS energy absorber,
a Bm’D or OXAN TRIACT-LOCK (international version) carabiner,
a CAPTIV positioning bar, and a RAY 11 mm static rope with sewn termination.
EAC
when used with an ASAP’SORBER or ASAP’SORBER AXESS energy absorber,
and an EN 1891 type A 10 to 13 mm rope.
XF 494 Light Use
GB/T 24537 when used with an OK TRIACT-LOCK carabiner and an ASAP’SORBER
or ASAP’SORBER AXESS energy absorber.
Absorbers for Mobile Fall Arresters
ASAP’SORBER
Energy absorber for ASAP and ASAP LOCK
The ASAP’SORBER energy absorber may only be used with an ASAP or ASAP LOCK mobile fall arrester.
It allows the user to work at a distance from the rope, in order to protect it during certain work phases.
Equipped with tear-webbing inside a pouch that opens on each end, the absorber is protected from
abrasion, while allowing for regular inspection. It is available in two lengths to provide the best balance
between distance from the rope and reduced fall distance.
ASAP’SORBER AXESS
Energy absorber for an ASAP or ASAP LOCK for a maximum load of 250 kg
The ASAP’SORBER AXESS energy absorber may only be used with the ASAP or ASAP LOCK mobile fall
arrester. It allows the user to work at a distance from the rope, in order to protect it during certain work
phases. Equipped with tear-webbing inside a pouch that opens on each end, the absorber is protected from
abrasion, while allowing for regular inspection. It can be used in two-person rescue situations for a maximum
load of 250 kg.
Ropes for Mobile Fall Arresters
ASAP’AXIS 11 mm
Low stretch kernmantle rope with sewn termination and integrated energy dissipater,
for use with an ASAP mobile fall arrester
The ASAP’AXIS 11 mm low stretch kernmantle rope with sewn termination and integrated energy dissipater
is designed for use with an ASAP mobile fall arrester. The energy dissipater is integrated with the rope
and meets the requirements of the European EN 353-2 standard for fall protection. The standard diameter
provides a good grip for easier handling. EverFlex technology provides great flexibility and consistent
performance over time. The sewn termination features the STUART accessory that helps keep the connector
in position to facilitate handling. Rope available in six lengths.
AXIS 11 mm With Sewn Termination
Low stretch kernmantle rope with sewn termination for use
with an ASAP LOCK mobile fall arrester
The AXIS 11 mm low stretch kernmantle rope with sewn termination is designed for use with an ASAP LOCK
mobile fall arrester and an ASAP’SORBER or ASAP’SORBER AXESS energy absorber. It has a sewn
termination with a protective sheath that helps keep the connector in position, allowing it to meet the
requirements of the European EN 353-2 standard for fall protection. The standard diameter provides
a good grip for easier handling. EverFlex technology provides great flexibility and consistent performance
over time. Rope available in six lengths.
RAY 11 mm With Sewn Termination
(only available in the United States)
Static rope with sewn termination for use with ASAP and ASAP LOCK mobile fall arresters
The RAY 11 mm static rope with sewn termination is designed for use with an ASAP or ASAP LOCK mobile
fall arrester. It has low elongation under load, allowing it to meet the requirements of the ANSI Z359.15
American fall protection standard. The standard diameter provides a good grip for easier handling.
EverFlex technology provides great flexibility and consistent performance over time. The sewn termination
with protective sheath helps keep the connector in position and makes handling easy. Rope available in
five lengths.
Mobile Fall Arresters
