KNEE ASCENT LOOP

Knee ascender assembly with foot loop to facilitate ascents on a single rope,

for tree care

The KNEE ASCENT LOOP assembly facilitates the arborist’s ascent when using the ZIGZAG

or ZIGZAG PLUS mechanical Prusik on a single rope. It contains an upper strap, a CROLL L

rope clamp, a lower strap with foot loop, and a TOOLBAG 1.5 tool pouch. The system is fully

adjustable and adapts to different body types.

KNEE ASCENT CLIP

Knee ascender assembly with boot connector, facilitating single rope ascents,

for tree care

The KNEE ASCENT CLIP assembly facilitates the arborist’s ascent when using the ZIGZAG

or ZIGZAG PLUS mechanical Prusik on a single rope. It contains an upper strap, a CROLL L

rope clamp, a lower strap with connector that attaches to the sewn webbing on the top of

the arborist’s boot, and a TOOLBAG 1.5 tool pouch. The system is fully adjustable and adapts

to different body types.

Catch to keep the rope

in the device during rope

ascents.

PANTIN

®

Foot ascender

The PANTIN foot ascender is used with the CROLL, ASCENSION, or ASCENTREE rope

clamps to make rope ascents faster and less tiring. It is available in right- and left-foot versions.

CROLL

®

Ventral rope clamp

Designed for rope ascents, the CROLL ventral rope clamp is simple to use, with a pinch

opening system, which is totally integrated in the clamp to avoid any involuntary snagging.

The attachment holes allow efficient positioning during ascents. It is available in two versions

to adapt to different rope diameters.

SECUR

Shoulder straps for positioning the CROLL ventral rope clamp

SECUR shoulder straps position the CROLL ventral rope clamp and attach to AVAO SIT,

FALCON, FALCON ASCENT, and SEQUOIA SRT harnesses.

ASCENTREE

Double-handled rope clamp for tree care

Handled rope clamp designed for double rope ascents, the ASCENTREE has ergonomic

handles allowing a comfortable and powerful grip when pulling. Catch/cam unit is totally

integrated to prevent any involuntary snagging.

PANTIN

left-foot

ASCENSION

left-handed

ASCENSION

right-handed

PANTIN

right-foot

The overmolded dual-density grip has

an area for the index finger and a wide,

supportive base to keep the hand

from slipping. Ergonomic upper part

maximizes power when pulling with

two hands.

ASCENSION

Handled rope clamp for rope ascents

The ASCENSION handled ascender is designed for rope ascents and features an overmolded

handle and ergonomic top section for a comfortable and powerful grip when pulling with one

or two hands. The ASCENSION handled rope clamp has a large lower hole for easily attaching

two carabiners for a lanyard and foot loop.

PROGRESS ADJUST-Y

Double adjustable progression lanyard

FOOTAPE

Adjustable webbing foot loop

The adjustable FOOTAPE foot loop is used with an ASCENSION or BASIC rope clamp for rope

ascents. A height-adjustable elastic band keeps the foot in the loop, regardless of shoe type.

FOOTCORD

Adjustable cord foot loop

The adjustable FOOTCORD foot loop is used with an ASCENSION or BASIC rope clamp

for rope ascents. Its high-modulus polyethylene construction increases durability.

A height-adjustable elastic band keeps the foot in the loop, regardless of shoe type.

LOOPING

Four-step etrier

The LOOPING four-step etrier attaches to an ASCENSION rope clamp for rope ascents

or directly onto an anchor for progression in overhangs.

Rope Clamps for Progression

Rope Clamps

Installing the

KNEE ASCENT
